Ultra-Lightweight 90kV Handheld Digital X-Ray Machine | Low Radiation Portable DR Generator Factory OEM
Quick Info.
- SKU NO.: UMY-XM-055
- Device Classification: Class Ⅱ
- Warranty: 1 Year
- Power Source: Electric
- Transport Package: Carton or Wooden Cases
- Origin: China
- Material: Aluminum & Magnesium Alloys and Plastic
- After-Sale Service: Online Technical Support
- Production Capacity: 2400 Sets/Year
This portable high-frequency 90kV digital X-ray machine provides clear and efficient imaging for both human and veterinary use. Designed with a compact structure, it ensures mobility without compromising on image quality. The machine operates with low radiation levels, making it a safe choice for both patients and operators. It works with advanced digital flat-panel detector ensuring superior clarity and precise diagnostics, making it ideal for emergency rooms, sports medicine, and more.
Explore our full line of veterinary imaging solutions.
Redefining mobile radiography with our advanced 90kV handheld high-frequency X-ray generator. Engineered with cutting-edge internal shielding to achieve industry-leading low radiation, this ultra-compact unit brings premium diagnostic power directly to home healthcare, emergency rescue, and veterinary clinics.
The Specific Parameters
| ITEMS | PARAMETERS |
|---|---|
| Power | 900W |
| kV | 40–90kV |
| mA | 1–10mA |
| X-ray Exposure Time | 0.1–2s |
| Cooling Time | Sixty times the exposure time |
| Focus Size | 0.8mm |
| Anode Heat Capacity | 7000J |
| Total Filtering | 1.8mm Al |
| Power Supply Method | Battery |
| Remote Exposure Interface | RJ11 |
| Image Processing | Optional |
| Environmental Specifications | |
| Working Environment Temperature | -10°C to +40°C |
| Physical Specifications | |
| Size | 225mm × 155mm × 263mm |
| Weight | 3.8kg |
Feature list for UMY-XM-055:
* Compact and portable design for easy transport
* High-frequency technology for efficient imaging
* Low radiation exposure for enhanced safety
* Digital flat-panel detector for clear, detailed images
* Optional support bracket and exposure handbrake
-
90kV High-Frequency Power Density: Don’t let the compact size fool you. With up to 90kV/10mA output, this unit delivers the deep tissue penetration required for human extremities, chest screening, and mixed-animal veterinary imaging, all while maintaining a minimal focal spot for razor-sharp clarity.
-
Certified Low-Radiation & Operator Safety: Safety is our absolute priority. Built with advanced internal lead-layer shielding and scatter-protection technology, it guarantees a market-leading low leakage radiation rate. Operators can safely execute handheld or strap-supported exposures with maximum peace of mind.
-
True Ergonomic Mobility: Featuring a streamlined, ultra-lightweight chassis and heavy-duty shoulder straps, it is built for effortless single-operator transportation. The intuitive, medical-grade touchscreen interface comes with pre-programmed APR (Anatomical Programmed Radiography) for one-touch parameter adjustment.
-
Rapid-Charge Battery & Advanced Cooling: Powered by a high-capacity, fast-charging internal lithium battery pack capable of delivering hundreds of exposures on a single charge. Enhanced thermal management ensures a highly efficient duty cycle, minimizing clinical wait times between shots.
-
Seamless Digital (DR) Synchronization: Engineered for seamless compatibility with leading wireless Flat Panel Detectors (FPD). Fully supports instant exposure linking and native DICOM 3.0 integration to easily sync with your clinic’s PACS network.
-
Verified OEM/ODM Customization Factory: Deal directly with a premium Chinese source manufacturer. We fully support your brand’s growth with flexible MOQs for custom housing colors, private labeling (logo silk-screening), tailored boot-up screens, and comprehensive regulatory documentation (ISO 13485 & CE technical dossiers) for smooth local registration.
Application:
Ideal for use in emergency rooms, sports medicine, orthopedics, ambulances, and rural medical visits. This versatile X-ray machine is also suited for field training and animal husbandry, providing detailed imaging in various environments.
