High-Resolution Medical Inkjet Film Printer with Built-in DICOM 3.0 Server | 14×17 Large Format X-Ray Imager | High-Dmax Radiology Dry Film Printer Factory OEM
Quick Info.
- SKU NO.: UMY-XM-072
- Device Classification: Class â…¡
- Warranty: 1 Year
- Power Source: Electric
- Transport Package: Carton or Wooden Cases
- Origin: China
- Material: Aluminum & Magnesium Alloys and Plastic
- After-Sale Service: Online Technical Support
- Production Capacity: 2000 Sets/Year
This Smart Value medical inkjet printer is designed for printing high-resolution digital X-ray films directly from DICOM imaging systems. It delivers sharp, diagnostic-quality images suitable for radiology, orthopedics, and general medical use. The system supports efficient and cost-effective film production without the need for expensive thermal printers or chemical processing. Its user-friendly design integrates seamlessly into existing PACS or RIS workflows, making it a reliable tool for clinics and diagnostic centers.
The Specific Parameters
| ITEMS | PARAMETERS |
|---|---|
| Printing Technology | |
| Print Technology | Inkjet |
| Resolution | 5760 × 1400 dpi |
| Print Speed | 13″ × 17″ – 12 sheets/h; other sizes calculated proportionally |
| Ink Cartridge | 6 Cartridges, 500ml per cartridge |
| Film Type | Medical printing film inkjet |
| Film Handling | |
| Film Supply | Top feed |
| Film Magazine | One magazine, capacity 50 sheets |
| Film Size | 13″ × 17″, 11″ × 14″, 10″ × 12″, 8″ × 10″, A4, A3 |
| Network Protocol | LAN network port, WIFI, SIM card |
| Power Supply | AC 220–240V, 50Hz / 49W (printing), 34.4W (idle) |
| Environmental Conditions | |
| Operating Temperature | 10 – 35 °C |
| Operating Humidity | 20% – 80% RH |
| Storage Temperature | 0 – 40 °C |
| Storage Humidity | 5% – 85% RH |
| Physical Specifications | |
| Weight | Gross: 32kg / Net: 24kg |
| Dimensions | 785(L) × 445(W) × 262(H) mm |
-
Native Built-In DICOM 3.0 Print Server: Eliminate the headache of external PC bridging or messy third-party software routers. Our printer features an advanced, built-in DICOM server, allowing it to connect directly to your local hospital network and seamlessly receive simultaneous print jobs from multiple DR, CT, and MRI workstations.
-
Diagnostic-Grade Grayscale & High Dmax: Engineered to satisfy strict radiology standards. When paired with our original ink and premium blue PET films, it achieves a maximum optical density (Dmax > 3.0). This ensures an ultra-smooth 256-grayscale transition, deep black tones, and sharp bone/tissue boundaries without banding artifacts.
-
Industrial Anti-Clogging Printhead Technology: Built around a highly resilient micro-piezo industrial printhead. Backed by automated firmware maintenance cycles, it prevents ink coagulation during weekend clinic closures, drastically reducing maintenance downtime and extending printhead life.
-
Encrypted IC Chip Lock-In for Localized Margins: We protect your recurring consumable revenue. For exclusive regional distributors, we offer custom-encrypted ink cartridge chips and regional film matching. This locks the lucrative follow-up ink and film supply chain exclusively to your business.
-
Flexible Multi-Format Media Trays: Adapt to any diagnostic request instantly. The top-loading high-capacity feed tray accepts all standard medical radiology film sizes, including 14×17 inch chest films, 11×14 inch, and 8×10 inch formats, with precise automatic alignment to avoid jamming.
-
Turnkey OEM/ODM Direct Factory Support: Source directly from an audited ISO 13485 medical manufacturing leader. We offer private-label branding, customized casing colorways, and multi-language localized touch-screen UIs. Complete technical dossiers are provided to secure fast local regulatory clearance.
