Portable Full Digital Veterinary Ultrasound Scanner with Sharp-Detail Imaging
SKU: UMY-VEUS-016
Brand: Umy
MOQ: 1
Origin: China
Quick Info.
- SKU NO.: UMY-VEUS-016
- Device Classification: Class Ⅱ
- Warranty: 1 Year
- Power Source: Electric
- Transport Package: Carton
- Origin: China
- Material: Metal, Plastic
- After-Sale Service: Online Technical Support
- Production Capacity: 3000 Sets/Year
This portable full digital veterinary ultrasound scanner provides sharp-detail imaging, ideal for precise diagnostics in reproductive, abdominal, and cardiac assessments for animals. Designed for easy use in both clinic and field environments, it offers high-quality visuals that enhance diagnostic accuracy for soft tissue and organ evaluations. Lightweight and reliable, it supports veterinarians in delivering thorough, on-the-spot care. This scanner is essential for veterinary professionals focused on detailed, portable imaging solutions.
The Specific Parameters
| ITEMS | PARAMETERS |
|---|---|
| General Specifications | |
| Imaging Mode | B, B+B, B+M, M |
| Gray Scales | 256 |
| Display | 7″ LCD |
| Transducer Frequency | 2.0–10MHz |
| Transducer Connector | 1 (standard) |
| Scanning Depth | From 45 to 250 mm (depending on probes) |
| System Language | English/Spanish |
| Imaging Processing | |
| Pre-processing | Edge enhancement, Near/Far field adjustment, 4 Focuses adjustment, Frame correlation |
| Post-processing | Gamma correction, Left-right reverse, Up-down reverse, 4 levels zoom |
| Functions | |
| Cine Loop | 365 frames bidirectional cine-loop |
| Zoom | x1.0, x1.2, x1.5, x2.0 in real-time |
| Storage Media | Built-in flash, external pen drive |
| Storage Capacity | Min. 1600 frames permanent storage |
| Body Mark | 24 types |
| Pseudo Color | 9 |
| Transducer Auto-detection | Supported |
| Measurement & Calculation | |
| B-mode | Distance, circumference/perimeter, area, volume, angle |
| M-mode | Distance, time, velocity, EF slope, heart rate |
| Display Parameters | |
| Display Content | Data, week, time, transducer model, transducer position, transducer frequency, depth, focus position, body marks, frame rate, measurement values, gain, etc. |
| Power Supply | AC 100-240V 50/60 Hz and DC |
| Physical Specifications | |
| Dimensions | 250mm (W) × 100mm (L) × 185mm (H) |
| Net Weight | 2.5Kg |
| Standard Configurations | |
| Main Unit | Included |
| Monitor | 7” LCD |
| Transducer Connector | One |
| USB Port | One |
| Carrying Straps | Two |
| Lithium Battery | One |
| Carrying Master Case | One |
| Cine Loop | 365 frames |
| Permanent Storage | Min. 1600 frames |
| Standard Probe | One rectal linear transducer (4.0/5.0/6.5/7.5MHz) |
| Software | Professional software packages |
| Professional Software Packages for Veterinary Use | |
| Canine-GW | EDCB (GSD, CRL, HD, BD) |
| Feline-GW | EDCB (HD, BD) |
| Sheep-GW | EDCB (CRL) |
| Swine-GW | EDCB (HL, SL) |
| Bovine-GW | EDCB (CRL, BBD, BTD, BUD) |
| Equine-GW | EDCB (GSD, ERD, ESD, EED) |
| Llama-GW | EDCB (BPD) |
| Optional | |
| Convex Transducer | 2.5/3.5/5.0MHz |
| Linear Transducer | 5.0/7.5/8.5/10.0MHz |
| Accessories | Car charger, Sun shade, Flash stick |
