Semi Auto Chemistry Analyzer with Flow Cell and Cuvette Testing Modes
Quick Info.
- SKU NO.: UMY-CA-002
- Device Classification: Class Ⅱ
- Warranty: 1 Year
- Power Source: Electric
- Transport Package: Carton or Wooden Cases
- Origin: China
- Material: Metal, Plastic
- After-Sale Service: Online Technical Support
- Production Capacity: 2200 Sets/Year
Power Source: Electric
Warranty: 1 year
After-sale Service: Online service and delivering spare parts
Transport Package: Carton or Wooden Cases
Material: Metal, Plastic
Instrument Classification: Class Ⅱ
Quality System Standard: ISO13485
This semi auto chemistry analyzer is designed for reliable biochemical testing in clinical laboratories requiring flexible and precise operation. It supports kinetic end point two point and absorbance test methods with real time curve display for clear result monitoring. The system features seven standard wavelengths and comes with eighty pre programmed test items to support routine and specialized assays. With ten incubators and three independent timers it allows efficient multitasking during daily laboratory workflows. Intelligent lamp hibernation extends light source lifespan while built in data storage supports up to ten thousand sample results.
This analyzer offers stable performance and intuitive operation for small to mid size clinical laboratories.
A related laboratory diagnostics category can be explored.
The Specific Parameters
| ITEMS | PARAMETERS |
|---|---|
| Technical Specifications | |
| Test Mode | Kinetic, End point, Two point, Absorbance |
| Wavelength | 7 standard filters: 340, 405, 492, 510, 546, 578, 630 nm; 1 free position |
| Wavelength Precision | ±2 nm, width ≤10 nm |
| Absorbance Range | 0–4.500 Abs |
| Absorbance Precision | Outside 0.0001 Abs; inside 0.00001 Abs |
| Incubators | 10 incubators, 37.0±0.3℃ |
| Timers | 3 timers, precision ±0.1 s |
| Carry-over | <1% |
| Repeatability CV | <1% |
| Flowcell Incubator | 37℃, 30℃, 25℃ and others; precision ±0.1℃ |
| Sample Volume | 0–3000 μL (500 μL recommended) |
| Data Storage | 10000 results |
| Quality Control | X̄, SD, CV%, L-J quality control curve for every test item |
| Flow Cell | 32 μL quartz glass, 10 mm |
| Light Source | Philips 6V 10W halogen lamp, long life |
| CPU | ARM series high-speed micro CPU |
| Display & Interface | |
| Screen | 7-inch color LCD |
| Printer | Internal thermal sensitive printer |
| Interface | RS-232 |
| Power & Environment | |
| Power Supply | 100–240 VAC, 50–60 Hz, 100 VA |
| Working Environment | Temperature 0℃–40℃; Humidity 80% |
| Physical Specifications | |
| Dimension | 340(L) × 270(W) × 160(H) mm |
| Weight | 5 kg |
| Application Test Menu | |
| Liver Function | ALT, AST, ALP, T-BIL, D-BIL, TP, ALB, TTT, CHE, NH₃ |
| Renal Function | BUN, CRE, UA, URE, CO2-CP, γ-GT |
| Lipids | T-CHO, TG, HDL-C, LDL-C |
| Cardiac Function | CK, CK-MB, LDH |
| Immune Proteins | IGA, IGG, IGM, C3 |
| Others | GLU, HGB, AMS |
Feature list for UMY-CA-002:
* Semi automatic chemistry analysis with flow cell and cuvette compatibility
* Seven inch color touch screen with real time curve display
* Seven wavelength optical system with eighty pre programmed test items
* Ten incubators with precise temperature control
* Three independent timers for flexible workflow management
* Flow cell incubator supporting multiple temperature settings
* High precision absorbance detection with low repeatability CV
* Light source hibernation function to extend lamp life
* Data storage for up to ten thousand sample results
* RS232 interface for PC connectivity
Application:
Designed for hospital laboratories outpatient diagnostic centers and clinical testing facilities performing routine biochemistry assays. Suitable for environments requiring accurate measurement flexible test modes and dependable quality control.
