Full Auto Chemistry Analyzer with High Throughput and Intelligent Liquid Handling
Quick Info.
- SKU NO.: UMY-CA-001
- Device Classification: Class Ⅱ
- Warranty: 1 Year
- Power Source: Electric
- Transport Package: Carton or Wooden Cases
- Origin: China
- Material: Metal, Plastic
- After-Sale Service: Online Technical Support
- Production Capacity: 2000 Sets/Year
Power Source: Electric
Warranty: 1 year
After-sale Service: Online service and delivering spare parts
Transport Package: Carton or Wooden Cases
Material: Metal, Plastic
Instrument Classification: Class Ⅱ
Quality System Standard: ISO13485
This full auto chemistry analyzer is designed to deliver stable and efficient biochemical testing for clinical laboratories. It supports multiple test methods including kinetic end point fixed time turbidimetry and absorbance measurement to cover a wide range of routine assays. With a throughput of up to one hundred twenty tests per hour and flexible cuvette options the system adapts to different laboratory workflows. Intelligent probe functions including liquid level detection anti collision protection and internal high pressure washing help ensure accuracy and long term reliability. The open reagent system and real time curve display support precise quality control and daily operation efficiency. A related laboratory diagnostics category can be explored.
This analyzer is suitable for laboratories seeking consistent performance with automated sample handling and minimal manual intervention.
The Specific Parameters
| ITEMS | PARAMETERS |
|---|---|
| Instrument Type | Fully Automatic Chemistry Analyzer |
| Test Categories | Liver function, Renal function, Lipids, Cardiac function, Diabetes, Inflammation, Coagulation, Others |
| Test Performance | |
| Test Speed | Up to 120 tests per hour |
| Test Modes | Kinetic, End-point, Fixed-time, Turbidimetry, Absorbance |
| Wavelength Range | 340–700 nm (8 wavelengths) |
| Absorbance Range | 0–4.000 Abs |
| Repeatability CV | < 1% |
| Carry-over | < 0.1% |
| Sample & Reagent Handling | |
| Sample Positions | 24 + 5 using original tubes |
| Reagent Positions | 54 (27 for 6 mL, 27 for 24 mL) |
| Cuvette Positions | 81 reusable cuvettes |
| Sample Volume | 2–30 µL, 0.1 µL increment |
| Reagent Volume | 20–350 µL, 0.1 µL increment |
| Quality Control | |
| Quality Control Curve | X̄, SD, CV%, L-J quality control for each test item |
| Display & Operation | |
| Display | 7-inch color LCD touch screen |
| User Interface | Real-time curve showing, intuitive operation |
| Memory Capacity | Up to 10,000 sample results |
| Printing & Connectivity | |
| Printer | Internal thermal sensitive printer |
| Interface | RS-232, PC connection |
| Water & Cleaning System | |
| Water Consumption | 5 L/hour for automatic washing; 2.5 L/hour for disposable cuvette mode |
| Probe System | Anti-collision probe with liquid level detection and high-pressure internal flushing |
| Power & Environment | |
| Power Supply | 100–240 VAC, 50/60 Hz, 100 VA |
| Working Environment | Temperature 10°C–30°C, Humidity ≤85% |
Feature list for UMY-CA-001:
* Fully automatic chemistry analysis with multiple testing modes
* Supports kinetic end point fixed time turbidimetry and absorbance methods
* Up to one hundred twenty tests per hour throughput
* Open reagent system with real time curve display
* Dual cuvette operation with automatic washing or disposable option
* Intelligent probe with liquid level detection and anti collision protection
* High pressure internal probe washing for reduced carry over
* Seven inch color touch screen with intuitive operation
* Memory storage for up to ten thousand sample results
* RS232 interface for PC connection and data transfer
Application:
Designed for hospital laboratories clinical diagnostic centers and reference labs performing routine and specialized biochemical testing. Suitable for environments requiring stable throughput accuracy and automated workflow control.
